Monocular Microscope
Product Details:
- Spare Parts Eyepieces, bulbs, fuse, objectives
- Focus System Coarse and fine adjustment knobs
- Theory Optical monocular microscopy
- Drawtube Straight drawtube
- Sensor Manual observations, no sensor
- Resolution Depends on eyepiece and objective, typically up to 1000x
- Magnification 100x to 1000x (using different eyepieces/objectives)
Monocular Microscope Price And Quantity
- 6900 INR/Piece
- 1 , , Piece
Monocular Microscope Product Specifications
- Manual observations, no sensor
- Optical monocular microscopy
- Depends on eyepiece and objective, typically up to 1000x
- Approx. 20 mm
- Eyepieces, bulbs, fuse, objectives
- Mechanical stage, 120 x 140 mm
- Monocular, fixed
- 100x to 1000x (using different eyepieces/objectives)
- Straight drawtube
- Monocular (single eyepiece tube)
- Not adjustable (monocular)
- Approx. 375 x 140 x 260 mm
- Coarse and fine adjustment knobs
- Widefield 10x and 15x
- Coarse and fine adjustment, total range approx. 25 mm
- Approx. 2 mm
Monocular Microscope Trade Information
- Cash in Advance (CID), Cash Advance (CA)
- 1 Week
Product Description
With the cooperation of a team of skilled and dedicated professionals, we have emerged as one of the leading manufacturers and suppliers of Monocular Microscope. In microbiological research centers the microscope is used for viewing very small objects through an eye piece and lens for the purpose of magnification. We use quality grade materials, sourced from the certified and reputed vendors to design the microscope. The clients can avail our Monocular Microscope in customized specifications and models as per their requirements.
Features:
-
Large stable base
-
Built in base halogen light source
-
Highly efficient
Further Details:
The Monocular Microscope that we offer is designed for various Laboratory applications. These Microscopes are assembled with precision and deliver clear results. Our range of Microscopes has superior features and components. They offer clear and magnified images of the specimen objects.
Technical Specifications
-
Inclined Binocular Body that is Rotatable through 360 degrees
-
Bearing based Quadruple revolving nose piece is flawlessly centered
-
Inclined Monocular head
-
Sub Stage
-
Abbe N.A.1.25 condenser, focusable with rack and pinion through 25mm constantly visible iris diaphragm with in built swing out filter holder.
-
Mechanical Stage
-
Large stable base with dimensions 120x125mm with co-axial precision graduated mechanical stage for X and Y movement of slide upto 50mm x 75mm
-
Coarse and fine focusing knob on both sides are provided for quick focusing
-
Highest quality paired Huy.5x Eye Piece for Anti Fungus Eye Pieces
-
Illumination
-
Fitted with built in base halogen light source
-
Equipped with 6v-20W Halogen bulbs
-
ON / OFF Switch and light intensity regulator
-
Complete with power cord and plug
-
Also a set of Plano-concave reflector provided for day light use
-
Anti Fungus Objectives
-
Parafocal, Achromatic Din Objectives 4x/5x, 10x, 40x/45x SL, 100x (SL) oil immersion.
Enhanced Optical Precision for Labs and Classrooms
Designed for clarity and ease of use, this microscope offers resilient construction and high-resolution optical performance suitable for students, researchers, and lab technicians. The versatile magnification range from 100x to 1000x makes it ideal for viewing a wide variety of specimens, while the mechanical stage and precise focus controls enable detailed explorations.
Reliable Operation and Low Maintenance
With AC 220V power supply, easily replaceable spare parts, and a protective dust cover, this monocular microscope ensures seamless operation and minimal downtime. The straightforward setup and robust design cater to educational and professional environments, providing reliable results with every use.
FAQs of Monocular Microscope:
Q: How do I adjust the magnification on the monocular microscope?
A: To change magnification, rotate the revolving nosepiece to switch between the three objective lenses. Pair with either the WF 10x or 15x eyepiece for a range of total magnifications between 100x and 1000x.Q: What is the process for focusing a slide?
A: Begin by placing the slide on the stage and securing it with the stage clips. Use the coarse adjustment knob to bring the specimen into general focus, then fine-tune the clarity with the fine adjustment knob. The total focus range is approximately 25 mm.Q: When should the spare parts like eyepieces or bulbs be replaced?
A: Spare parts such as eyepieces, bulbs, fuses, and objectives should be replaced if you notice diminished image quality, illumination failures, or physical damage. Regular checks after heavy usage will help maintain optimal performance.Q: Where can I purchase this monocular microscope in India?
A: This microscope is available from exporters, manufacturers, suppliers, traders, and wholesalers throughout India. You can contact educational or laboratory equipment providers for quotations and purchases.Q: What are the benefits of using a monocular microscope with a mechanical stage?
A: A mechanical stage allows smooth, controlled movement of slides, making it easier to observe various sections of your specimen without losing focus. This feature, combined with the stable stage clips, enhances both precision and convenience during microscopic examinations.Q: How do I properly clean and store the microscope?
A: After use, cover the microscope with the included dust cover. Use a clean, soft cloth and lens cleaning paper to wipe optical surfaces. Store it in a dry place and ensure it is unplugged when not in use.
