Tool Maker Microscope
Product Details:
- Focus System Rack and pinion with fine and coarse movement
- Spare Parts Spare bulb, fuse, and stage glass available on request
- Features High precision measurement, robust metallic construction, interchangeable objectives and eyepieces, angle measurement attachment, cross hair for alignment.
- Theory Tool makers microscope is an essential measuring instrument used for precise measurement and inspection of miniature and intricate mechanical parts by comparing their features with a reference scale.
- Drawtube Monocular
- Resolution 0.01 mm or better
- Interface Manual
X
Tool Maker Microscope Price And Quantity
- 1 Piece
Tool Maker Microscope Product Specifications
- WF10x
- Fixed condenser with iris diaphragm
- 10x and 20x achromatic objectives
- Approx. 350 x 260 x 450 mm Millimeter (mm)
- Up to 100x (objective 10x & 20x with eyepiece 10x)
- High precision measurement, robust metallic construction, interchangeable objectives and eyepieces, angle measurement attachment, cross hair for alignment.
- 0.01 mm or better
- Monocular
- Transmitted and incident LED lighting
- Manual
- 15 mm
- 0.002 mm per division
- Spare bulb, fuse, and stage glass available on request
- 45 inclined, 360 rotatable
- Tool makers microscope is an essential measuring instrument used for precise measurement and inspection of miniature and intricate mechanical parts by comparing their features with a reference scale.
- Rack and pinion with fine and coarse movement
- Monocular head, inclined at 45
Tool Maker Microscope Trade Information
- 100 Piece Per Month
- 7 Days
Product Description
The professional approach and extensive experience of our workforce in this field have enabled us to manufacture and supply Tool Maker Microscope. These microscopes are highly ideal for measuring diameter of a measuring tool. To design the microscope we use finest quality materials, procured from the most reputed vendors of the market. We have made the Tool Maker Microscope available for the clients in different customized designs, models and specifications as per their requirements.
Features:
-
Easy to use
-
Excellent performance
-
Sturdy construction
Further Details:
TECHNICAL SPECIFICATIONS:
Eyepieces: WF10x(withcross)H10x (with micrometer)& H 15x
Objectives : 1x - 3x - 5x
Filed of view: 10mm - 3.5mm - 2mm
Magnifications: 10x - 15x - 30x - 45x - 50x and 75x.
MEASURING STAGE: 125mm x 125mm with interchangeable intermediate table to receive different optional accessories. Equipped with micrometer head 0-25mm reading 0.01 mm, life long smooth movement is assured by the incorporation of hard steel rolling balls both in longitudinal and transverse slides. Rotary Measuring stage dia 130mm is mounted on the table with 55mm glass aperture, circular graduated scale is divided into 360 with both side vernier reading 5 minutes.
OBSERVATION TUBE: Monocular inclined at 45 fitted with Gonio-metric head graduated 360.
ILLUMINATIONS : Two possible range of illuminating systems are provided with standard equipment to meet every application, operated through 6 volts solidstate variable light control built-in transformer.
(1) Sub-stage transmitted light from a bottom source providing collimated green filtered Halogen light for viewing contours and transparent objects.
(2)Surface incident illuminator for high power examination of opaque objects.
Precision Measurement Capabilities
The Tool Maker Microscope is engineered for exceptionally accurate measurements, thanks to its refined micrometer scale, high-resolution optics, and precise stage movement. The 0.01 mm least count allows operators to scrutinize intricate components, ensuring adherence to tight tolerances. Its monocular view head with fine and coarse adjustment features supports detailed inspections, making it indispensable for precision engineering tasks.
Versatile Design and Robust Construction
Built with robust metallic components, this microscope offers reliable durability in demanding workshop conditions. Its interchangeable objectives (10x and 20x achromatic) and angled eyepiece tube allow ergonomic operation, while the vee block attachment is perfect for inspecting cylindrical parts. The 360 rotatable stage with fine angular adjustment streamlines complex alignment and measurement procedures.
User-Friendly Operation and Illumination
The manual interface and intuitive focusing system, combined with transmitted and incident LED lighting, provide clear visibility and ease of use during measurements. The rack and pinion focus system ensures smooth adjustments, while the fixed condenser and iris diaphragm optimize contrast and clarity for diverse sample types. Spare parts are readily available for maintenance, ensuring consistent performance.
FAQs of Tool Maker Microscope:
Q: How does the Tool Maker Microscope achieve precise measurements of mechanical parts?
A: The microscope combines a fine micrometer scale with a least count of 0.01 mm, precision rack and pinion focus system, and high-quality achromatic objectives to deliver accurate measurements of miniature and intricate parts.Q: What is the process for measuring angular features using this microscope?
A: Angular measurements are conducted with the 360 rotary stage featuring fine angular adjustment and a vernier scale resolution of 6 minutes, allowing users to precisely align and quantify angles in the sample.Q: Where is the Tool Maker Microscope commonly used?
A: This microscope is extensively employed in tool rooms, quality control labs, manufacturing units, and research facilities for inspecting and measuring small components with high accuracy.Q: When should I use the vee block attachment provided with the microscope?
A: The vee block attachment is essential for securely positioning and measuring cylindrical jobs, ensuring stable alignment and preventing sample movement during inspection.Q: What are the benefits of LED illumination in this microscopy system?
A: LED illumination (both transmitted and incident) offers bright, energy-efficient lighting, enhancing sample visibility and detail during measurements without generating excessive heat.Q: How can users ensure consistent accuracy with this microscope?
A: Regular calibration, careful handling, and timely replacement of spare parts such as bulbs and stage glass will maintain the instruments measurement precision and operational reliability.Tell us about your requirement
