Trinocular Inverted Tissue Culture

Get a Price/Quote

MOQ : 1 Piece

Trinocular Inverted Tissue Culture Specification

Focus System
Coaxial coarse and fine focus adjustment

Spare Parts
Supplied with dust cover, fuse, cord, and operation manual

View Head
Trinocular, inclined 45, rotatable 360

Drawtube
Trinocular

Magnification
40x to 400x, expandable to 1000x with suitable objectives

Eyepiece Tube
Inclined 45, 360 rotatable trinocular head

Illumination
6V 20W Halogen Lamp with intensity controller

Interpupillary Distance
Adjustable 55 75 mm Millimeter (mm)

Stage Size
Mechanical stage size approximately 210 x 240 mm

Power Supply
220V AC, 50Hz

Stage Plate
Glass stage insert for Petri dishes & culture flasks

Stage Movement
Travel range 75 x 50 mm

Trinocular Inverted Tissue Culture Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About Trinocular Inverted Tissue Culture

Zoom Trinocular Tissue Culture Microscope : Inverted trinocular microscope for tissue culture examination having Co-axial coarse and fine focusing system, Triple layer co-axial mechanical stage for X-Y movement of specimen incident lamp with variable light control arrangement, with long working distance objectives and trinocular head, complete with following optics in box.

Superior Imaging and Flexibility

The microscopes backward quadruple nosepiece allows seamless switching between objectives, making it optimal for complex tissue culture investigations. Its trinocular design, combined with an adjustable interpupillary distance (5575 mm), ensures clear imaging and adaptability for multiple users, including integration of photographic and digital camera accessories.

Precision Stage and Ergonomic Focus

Equipped with a spacious 210 x 240 mm mechanical stage and a 75 x 50 mm travel range, this microscope accommodates large culture vessels. Its coaxial coarse and fine focus system provides smooth, accurate depth control, essential for delicate cell culture work. The glass stage insert easily supports Petri dishes and flasks for diverse experimental needs.

FAQs of Trinocular Inverted Tissue Culture:

Q: What applications is the Trinocular Inverted Tissue Culture Microscope suitable for?

A: This microscope is primarily designed for cell culture and tissue study applications in laboratories and research institutes, where inverted optics and precise stage control are necessary for observing live specimens in culture vessels.

Q: How does the backward quadruple nosepiece benefit tissue culture studies?

A: The backward quadruple nosepiece enables users to swiftly change objectives, streamlining multi-step observation protocols and facilitating uninterrupted workflow during tissue culture examinations.

Q: Where can I use or install this microscope?

A: The microscope is ideal for laboratory settings and research facilities involved in cell biology, biotechnology, and tissue engineering, owing to its robust design and compatibility with common culture vessels.

Q: What is the process of magnification expansion on this microscope?

A: Magnification ranges from 40x to 400x with standard objectives, and can be extended to 1000x by installing suitable high-power objectives, allowing users to tailor the system for detailed analysis as needed.

Q: Which accessories enhance the usage of this microscope?

A: Optional accessories like phase contrast attachments, digital camera adapters, photographic attachments, and cooling plates expand imaging capabilities, documentation, and sample handling, increasing the microscopes versatility.

Q: What benefits does the 45 inclined, 360 rotatable trinocular head provide?

A: The ergonomic trinocular head allows comfortable, prolonged viewing and allows for simultaneous image capture and sharing, which is especially valuable in collaborative research and digital documentation.
